Eco-friendly Paper Bag Manufacturing Machine Price Non Woven Fabric Bag Making Machine
1.Product introduction of Paper Bag Manufacturing Machine Price:
This machine uses HDPE, LDPE, PLA, PBAT tubular film as raw materials to produce printed, natural color, and vest bags. It adopts PIC control, dual servo (stepping) motors for fixed length, and LCD touch screen for real-time display. It can complete the feeding, cutting, punching, and conveying in one go, with a high degree of automation and good economic benefits.
2.Technical parameters & Quotation of Paper Bag Manufacturing Machine Price:
Continuous Heat Sealing and Cold Cutting Bag Making Machine
|
Model |
WM-Z600 |
WM-Z800 |
WM-Z1000 |
|
Max.Sealingand Cutting Width |
500mm |
700mm |
900mm |
|
Sealing and Cutting Length |
1500mm |
1500mm |
1500mm |
|
Sealina and Cuttina Thickness |
0.004-0.10mm |
0.004-0.10mm |
0.004-0.10mm |
|
Error in Length |
±1mm |
±1mm |
±1mm |
|
Bag-Making Speed |
40-120pcs/min |
40-120pcs/min |
40-120pcs/min |
|
Power of Main Motor |
1.1kw6 level |
1.1kw6 level |
1.1kw6 level |
|
Heating Power |
1.5kw |
1.5kw |
1.5kw |
|
Total Power |
3.4kw |
3.4kw |
3.4kw |
|
Weight |
700kg |
800kg |
850kg |
|
Dimension(mm) |
3200x1300x1500 |
3200x1500x1500 |
3200x1700x1500 |
Flower Bag Making Machine
|
Model |
WM-XHZ800 800 single-blade flower bag making machine |
|
Main engine |
1.5 KW |
|
Three-layer conveyor belt motor for collecting |
400W |
|
Unloading Magnetic Powder |
2.5W Double unloading: with one collecting |
|
Unloading Motor |
400W |
|
Machine Weight |
1000kg |
|
Machine Size |
1400*5500 *1500 |
|
Output |
70 pieces/hour |
